CO-NELE intensive mixers are designed for demanding refractory mixing applications where uniformity, dispersion and reliable material handling are critical.
Refractory production often involves a combination of aggregates, fine powders, binders and additives. These materials can be difficult to mix evenly, especially in formulations with high solid content and low moisture.
The CO-NELE intensive mixer uses a high-speed mixing system to generate strong shear and turbulent movement inside the mixing chamber. This helps distribute fine powders, aggregates and binders more evenly, producing a consistent mixture for the following forming, pressing or casting process.
Designed for Different Refractory Materials
The refractory intensive mixer can be used for a wide range of refractory formulations, including:
* Magnesia Carbon Bricks
* Alumina Refractories
* Silicon Carbide Refractories
* Mullite Refractories
* Refractory Castables
* Monolithic Refractories
* High-Alumina Refractory Products

* Other Special Refractory Compounds

$Intensive Mixer for Refractory Materials | CO-NELE$

Intensive Mixer for Refractory Materials | CO-NELE

Why Use an Intensive Mixer for Refractory Production?
1. Strong Mixing Action
The combination of the rotating mixing plate and high-speed eccentric rotor creates intensive material movement. The resulting shear and turbulent flow help break up agglomerates and improve the dispersion of different components.
2. Uniform Distribution of Binders and Additives
Refractory formulations may contain relatively small amounts of binders, additives or other functional components. Intensive mixing helps distribute these components throughout the batch more consistently.
3. Suitable for High-Solid Materials
Refractory mixtures typically contain a high proportion of aggregates and powders. The intensive mixing principle is well suited to materials with high solid content and demanding mixing characteristics.
4. Wear-Resistant Configuration
Refractory raw materials such as alumina, silicon carbide and magnesia can cause significant abrasion during mixing. CO-NELE intensive mixers can be configured with wear-resistant liners and components according to the material characteristics and production requirements.
5. Flexible Mixing Solutions

Different refractory products require different mixing capacities and process conditions. CO-NELE provides multiple intensive mixer models and configurations to match laboratory development, pilot production and industrial-scale manufacturing.

$Intensive Mixer for Refractory Materials | CO-NELE$

Intensive Mixer for Refractory Materials | CO-NELE

Refractory Applications
- Magnesia Carbon Brick Production
Magnesia carbon brick production requires the homogeneous mixing of magnesia aggregates, graphite, resin and various additives.
A high-intensity refractory mixer can help achieve consistent distribution of the binder and fine components before the mixture enters the pressing process.
Typical application:
Magnesia + graphite + resin + additives → intensive mixing → pressing → heat treatment
- Alumina Refractory Materials
Alumina-based refractory formulations may contain different particle sizes, from coarse aggregates to fine powders.
The intensive mixing process helps improve the distribution of these components and provides a more homogeneous mixture for subsequent forming or casting.
- Silicon Carbide Refractories
Silicon carbide is highly abrasive, making wear resistance an important consideration for the mixing equipment.
For SiC-based refractory production, the mixer can be equipped with suitable wear-resistant components according to the material characteristics and expected service conditions.
- Mullite Refractories
Mullite-based formulations can contain aggregates, fine powders, binders and additives.
The intensive mixing process provides strong material circulation and helps achieve consistent component distribution throughout the batch.
CO-NELE Intensive Mixer for Refractory Materials
The CR series intensive mixer is built for applications requiring strong mixing, high homogeneity and efficient processing of demanding materials.
Its mixing principle combines:
Rotating Mixing Plate + High-Speed Eccentric Rotor
This creates three-dimensional turbulent material movement, allowing the material to circulate rapidly through different areas of the mixing chamber.
For refractory applications, the mixer can be configured according to:
* Material type
* Batch capacity
* Particle size
* Abrasiveness
* Binder type
* Mixing process
* Required production capacity

* Wear-resistance requirements

Frequently Asked Questions
- What is an intensive mixer for refractory materials?
An intensive mixer for refractory materials is a high-shear mixing machine designed to homogenize refractory aggregates, powders, binders and additives. It is particularly useful for formulations with high solid content or difficult-to-mix components.
- What refractory materials can be mixed?
CO-NELE intensive mixers can be used for formulations based on magnesia, alumina, silicon carbide, mullite and other refractory raw materials, subject to the specific material characteristics and process requirements.
- Can it be used for magnesia carbon bricks?
Yes. Intensive mixing is commonly used to homogenize magnesia aggregates, graphite, resin and additives before the material is sent to the pressing process.
- What about highly abrasive materials such as silicon carbide?
Yes. For highly abrasive materials, suitable wear-resistant liners and components can be selected according to the specific application.
- How do I select the right refractory mixer?
The appropriate model depends on batch volume, material characteristics, formulation, particle size, binder system and required production capacity. CO-NELE can recommend a suitable configuration based on the customer's process parameters.
Looking for an intensive mixer for refractory production?
Tell us your refractory material, batch size, formulation and required capacity. CO-NELE can recommend a suitable intensive mixing solution for your production process.
