CO-NELE intensive mixers are designed as granulating and pelletizing mixers which produce predictable and reproducible grain sizes.
Just one machine is needed to carry out the two process steps:mixing and granulating/pelletizing.
Technical advantages of CO-NELE mixing granulator
High spheroidization rate, uniform particle size, good particle shape and strong particle density
Rotary mixing drum and granulation tool set are controlled by variable frequency, the speed can be adjusted, the particle size can be controlled by adjusting the speed, and the particle size can be adjusted online
Unloading method Tipping unloading or bottom unloading (hydraulic control), quick and clean unloading, easy to clean
A complete range of models, from small laboratory (5-10L) granulation to large industrial pelletizing, can meet the needs
It has a wide range of applications and can meet the mixing needs of different industries and various materials
Granulator application industry
ceramics
Molding materials, molecular sieves, proppants, varistor materials, dental materials, ceramic tools, abrasive materials, oxide ceramics, grinding balls, ferrites, etc.
building materials
Porous media of bricks, expanded clay, perlite, etc., refractory ceramsite, clay ceramsite, shale ceramsite, ceramsite filter material, ceramsite brick, ceramsite concrete, etc.
Glass
Glass powder, carbon, leaded glass frit, waste glass slag, etc.
metallurgy
Zinc and lead ore, alumina, carborundum, iron ore, etc.
chemical
Slaked lime, dolomite, phosphate fertilizers, peat fertilizers, mineral materials, sugar beet seeds, fertilizers, phosphate fertilizers, carbon black, etc.
Environmental friendly
Cement filter dust, fly ash, sludge, dust, lead oxide, fly ash, slag, dust, etc.
Carbon black, metal powder, zirconia
The mixing pan can be arranged either horizontally or at an optimized angle of inclination to suit the particular requirements.
Higher tool speeds can be used for example to - optimally solubilize fibers - completely pulverize pigments - optimize mixing of fine fractions - manufacture suspensions with a high solid content Medium tool speeds are used to - achieve mixtures with a high mixture quality At lower tool speeds - lightweight additives or foams can be gently added to the mixture．
Higher tool speeds can be used for example to: - optimally solubilize fibers - completely pulverize pigments, optimize mixing of fine fractions - manufacture suspensions with a high solid content.
CO-NELE intensive mixers are designed as granulating and pelletizing mixers which produce predictable and reproducible grain sizes. Just one machine is needed to carry out the two process steps: mixing and granulating/pelletizing.
Type | CR02 | CR04 | CR05 | CR08 | CR09 | CRV09 | CR11 | CR15 | CRV15 | CR19 | CRV19 | CR24 | CRV24 |
In capacity(L) | 7.5 | 15 | 37 | 75 | 150 | 225 | 375 | 525 | 750 | 1125 | 1500 | 2250 | 3000 |
Out capacity(L) | 5 | 10 | 25 | 50 | 100 | 150 | 250 | 350 | 500 | 750 | 1000 | 1500 | 2000 |
Mixing device | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Paddle | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
